X1-F510

Vehicle-Mounted Counter-UAV System
  • Detection
  • Jamming
  • Spoofing
  • Electro-optical
  • Radar
  • RF-Spectrum
The X1-F510 is a fully integrated vehicle-mounted counter-UAS system combining detection, identification, localization, and jamming in one unit. It enables rapid response and effective neutralization of UAV threats in dynamic environments. With wideband detection (300–6200 MHz), the system can identify UAV models, decode key data, and locate both drones and operators in real time. The integrated jamming module provides multi-band suppression to disrupt control, navigation, and video links, forcing drones to land or return.Designed for mobile deployment, it supports vehicle power supply, 24/7 operation, and automatic detect-and-counter response, ensuring continuous low-altitude security on the move.

Detection Frequency Range: 300 MHz–6200 MHz

Detection Distance: 3–5 km

Detection Response Time: ≤ 3 s

  • Category:
    Integrated Systems
    Share:
    All-in-One Detection & Jamming

    Integrated system for detect, identify, locate and neutralize UAVs in one unit

    Wideband detection up to 5 km

    300 MHz – 6.2 GHz coverage for mainstream and FPV drones

    Omnidirectional Multi-band Jamming

    10-band suppression with up to 3 km effective range

    Real-time UAV & pilot identification & localization

    Identify drone model, location, and operator position instantly

    Vehicle-Mounted Rapid Deployment

    Designed for mobile missions with 24/7 autonomous operation

    Detection Frequency Range

    300 MHz–6200 MHz

    Detection Distance

    3–5 km

    Detection Response Time

    < 3s

    Detection Sensitivity

    > -96 dBm

    Localization Error

    ≤10 m

    Jamming Range

    1–3 km

    Jamming Frequency Bands

    400–550 MHz / 700–840 MHz / 840–1000 MHz / 1100–1300 MHz / 1300–1500 MHz / 1550–1620 MHz / 2400–2500 MHz / 3300–3600 MHz / 5100–5300 MHz / 5700–5900 MHz

    Total RF Power

    420 W

    Power Consumption

    1100 W

    Input Voltage

    DC 24V

    Alarm Log Capacity

    500 alarm entries

    Protection Level

    IP65 (Rainproof)
